ESE-SS Portable Fume Extractor with HEPA Filter Options
Designed for mobile welding and industrial applications, the SE1602 welding fume extractor captures contaminants close to the source and recirculates filtered air back into the workspace. Choose from disposable, washable, HEPA and carbon filtration options.
Key Features
- Up to 225 CFM airflow
- 160 CFM tested under full load
- 80" W.G. maximum vacuum
- Stainless-steel chrome construction
- Portable source-capture design
- Optional HEPA filtration
- Washable filter option available
- Optional activated carbon filtration
- 120V / 50–60 Hz operation
- Recirculates filtered air
Technical Specifications
| Specification | Details |
|---|---|
| Model | SE1602 / ESE-SS |
| Product Type | Portable Welding Fume Extractor |
| Airflow – No Load | 225 CFM (382 m³/hr) |
| Airflow – Full Load | 160 CFM (270 m³/hr), tested with nozzle & 25 ft hose |
| Standard Filter Efficiency | 99.5% with EF400 |
| Filtration | Single-Stage or Primary/HEPA Combination |
| Maximum Vacuum | 80" W.G. (21 kPa) |
| Motors | 1 or 2 |
| Motor Type | Bypass |
| Voltage | 120 VAC / 50–60 Hz |
| Amperage | 13A |
| Hose Length | 15 ft (4.6m) |
| Hose I.D. | 1.75" (45mm) |
| Dimensions | 14.5"H × 9.25"W × 26.5"L |
| Housing | Stainless Steel / Chrome |
Available Filter Options
| Filter | Application |
|---|---|
| EF400 | 99.5% Efficient Disposable Filter |
| EF200A | Washable / Reusable Filter |
| EF100 + EF200 | Primary + HEPA Dual-Stage System |
| EF600 / 102.1006 | Combi HEPA Filter |
| ECF100A | Activated Carbon Filter for Odor & Gas Control |
Best For
✓ Welding Fume Extraction
✓ Portable Source Capture
✓ Welding Workstations
✓ Fabrication Shops
✓ Maintenance & Repair
✓ Mobile Industrial Applications
FAQs
What is the airflow of the SE1602?
The SE1602 delivers up to 225 CFM no-load airflow and 160 CFM under the specified full-load test configuration.
Does the SE1602 support HEPA filtration?
Yes. HEPA, disposable, washable and activated carbon filtration configurations are available.
Is the SE1602 portable?
Yes. Its compact design makes it suitable for moving between welding stations and industrial work areas.
Does it recirculate filtered air?
Yes. Filtered air can be returned to the workspace rather than requiring outdoor exhaust.
What power supply does it use?
The SE1602 operates on 120 VAC, 50/60 Hz with a listed amperage of 13A.
For more details or to discuss specific requirements, please contact Simplex Global Inc. at +1 (647)451-1094 or email info@simplexglobalinc.com
