Handheld Fume Extractor - Low Vacuum Models
7-Day Money-Back Guarantee
Shipping: Same day dispatch or delivery within 2–5 business days
| Model | ESE101A-W-2 | ESE201A-W-2 | ESE102A-2 | ESE202A-2 |
|---|---|---|---|---|
| Air Flow With Load Conditions (Hose and Nozzle Connected) | 80 C.F.M. (135 m3/hr) | 160 C.F.M. (270 m3/hr) | 80 C.F.M. (135 m3/hr) | 160 C.F.M. (270 m3/hr) |
| Air Flow With No Load Conditions (No Hose or Nozzle Connected) | 113 C.F.M. (192 m3/hr) | 225 C.F.M. (382 m3/hr) | 113 C.F.M. (192 m3/hr) | 225 C.F.M. (382 m3/hr) |
| Filtration Efficiency | 0.3 – 1 um (46%), 1.0 -3.0 um (61%), 3.0 -10 um (95%) | 0.3 – 1 um (46%), 1.0 -3.0 um (61%), 3.0 -10 um (95%) | (EF100-1.0-3.0 Microns (50%-64.9%),3.0-10.0 Microns (85% or greater)) (EF200-0.3 -1 Micron (99.97%)) | (EF100-1.0-3.0 Microns (50%-64.9%),3.0-10.0 Microns (85% or greater)) (EF200-0.3 -1 Micron (99.97%)) |
| Number of Filters | 1 (EF200A)*** | 1 (EF200A)*** | 2 (EF100+EF200) | 2 (EF100+EF200) |
| Type of Filters | Washable | Washable | Throwaway | Throwaway |
| Maximum Vacuum | 80”W.G. (21 KPA) | 80”W.G. (21 KPA) | 80”W.G. (21 KPA) | 80”W.G. (21 KPA) |
| Number of Motors | 1 | 2 | 1 | 2 |
| Type of Motors | Bypass | Bypass | Bypass | Bypass |
| Voltage | 120 Volts, 50/60 HZ | 120 Volts, 50/60 HZ | 120 Volts, 50/60 HZ | 120 Volts, 50/60 HZ |
| Amperage | 6.5 amps | 13 amps | 6.5 amps | 13 amps |
| Dimensions | L 26 ½” X W 9 ¼” X H 14 ½” | L 26 ½” X W 9 ¼” X H 14 ½” | L 26 ½” X W 9 ¼” X H 14 ½” | L 26 ½” X W 9 ¼” X H 14 ½” |
| Weight | 37Lbs. | 41Lbs. | 39Lbs. | 43Lbs. |
| Hose Length | 15ft. (4.6M) | 15ft. (4.6M) | 15ft. (4.6M) | 15ft. (4.6M) |
| Hose I.D. | 1¾” (45mm) | 1¾” (45mm) | 1¾” (45mm) | 1¾” (45mm) |
Key Features:
- Portability: Lightweight, suitcase-sized design for easy transport and maneuverability, ideal for maintenance and repair welding tasks.
- Efficient Filtration: Equipped with a high-efficiency washable filter, with optional charcoal and HEPA filters for enhanced gas and particulate removal.
- Versatile Hose Options: Comes standard with a 15 ft. hose; optional 25 or 50 ft. lengths available to suit various workspace requirements.
- Dual Motor Configurations: Available in single or dual motor setups (120V 50/60Hz) to accommodate different extraction needs.
- Durable Construction: Optional stainless steel cabinet for use in corrosive environments, ensuring longevity and reliability.
- Multiple Nozzle Choices: Offers 3” or 8” wide nozzles with base, magnet, and metal flex duct for targeted fume capture.
- Energy Efficiency: Recycles clean air back into the facility, reducing additional heating or cooling costs.
Product Overview:
Enviroflex’s ESE Hand-held Welding Smoke Extractor is engineered to provide superior fume extraction directly at the source, safeguarding workers from inhaling hazardous airborne particulates. Its compact and portable design makes it an excellent choice for both field and bench work, especially in maintenance and repair welding scenarios. The unit’s high-efficiency washable filter effectively captures contaminants, while optional charcoal and HEPA filters enhance its capability to remove various gases and fine particulates, including hexavalent chromium fumes from stainless steel welding.
The extractor’s versatility is further highlighted by its customizable hose lengths and multiple nozzle options, allowing operators to adapt the system to specific tasks and environments. For operations in corrosive settings, the optional stainless steel cabinet ensures durability and extended service life. By recycling purified air back into the workspace, the ESE Hand-held Extractor not only promotes a healthier work environment but also contributes to energy savings by maintaining consistent indoor climate conditions.
Frequently Asked Questions (FAQs):
- Why is a fume extractor necessary for welding operations?
Welding processes emit fumes containing harmful metals and gases. Using a fume extractor like the ESE HandHeld model captures these contaminants at the source, protecting the operator’s health and maintaining air quality standards. - Can the ESE Hand-held Extractor be used for materials other than stainless steel?
Yes, the extractor is suitable for various materials, including asbestos, silica, carbon dust, fiberglass, galvanized steel, and lead oxides, effectively capturing hazardous particulates across different applications. - What maintenance is required for the filters?
The unit comes with a high-efficiency washable filter. Regular cleaning ensures optimal performance. Optional throwaway paper filters and HEPA filters are also available, depending on specific needs and regulations. - Is the extractor suitable for use in confined or hard-to-reach spaces?
Absolutely. Its portable design and flexible hose options make it ideal for maneuvering in tight or confined areas, ensuring effective fume extraction wherever needed. - Does the unit support multiple workstations simultaneously?
With the optional ‘Y’ connector, the ESE Hand-held Extractor can service two stations from a single unit, enhancing its versatility and efficiency in multi-operator environments.
Additional Information:
Enviroflex’s commitment to quality and innovation is evident in the design of the ESE Hand-held Welding Smoke Extractor. By focusing on source capture, the unit ensures that harmful fumes are removed before they reach the operator’s breathing zone, promoting a healthier and more productive workspace. The energy-efficient design not only protects workers but also contributes to operational cost savings, making it a valuable addition to any welding operation.
For more details or to discuss specific requirements, please contact Simplex Global Inc. at +1 (647)451-1094, or email info@simplexglobalinc.com
